hydraulic quick coupler

This EH series is interchangeable with the Faster 4BD4FH Spare Part Kit and Faster 4BD4FH Accessories. Steel Product. This pioneering cast iron block was the first of its kind to enable the rapid connection and disconnection of attachments for skid steer loaders and similar construction machinery. It utilizes cartridges that incorporate the full benefits of flat face coupler series technology, including a decompression feature for safe coupling even with residual pressure on both sides of the circuit. The block accepts both 1/2" and 3/4" cartridges, with the larger size providing a higher flow capacity while maintaining the same compact footprint.

This EH series is interchangeable with the Faster 4BD4FH Spare Part Kit and Faster 4BD4FH Accessories. Steel Product. This pioneering cast iron block was the first of its kind to enable the rapid connection and disconnection of attachments for skid steer loaders and similar construction machinery. It utilizes cartridges that incorporate the full benefits of flat face coupler series technology, including a decompression feature for safe coupling even with residual pressure on both sides of the circuit. The block accepts both 1/2" and 3/4" cartridges, with the larger size providing a higher flow capacity while maintaining the same compact footprint.

This EH series is interchangeable with the Faster 4BD4FH Spare Part Kit and Faster 4BD4FH Accessories. Steel Product. This pioneering cast iron block was the first of its kind to enable the rapid connection and disconnection of attachments for skid steer loaders and similar construction machinery. It utilizes cartridges that incorporate the full benefits of flat face coupler series technology, including a decompression feature for safe coupling even with residual pressure on both sides of the circuit. The block accepts both 1/2" and 3/4" cartridges, with the larger size providing a higher flow capacity while maintaining the same compact footprint.

This EH series is interchangeable with the Faster 4BD4FH Spare Part Kit and Faster 4BD4FH Accessories. Steel Product. This pioneering cast iron block was the first of its kind to enable the rapid connection and disconnection of attachments for skid steer loaders and similar construction machinery. It utilizes cartridges that incorporate the full benefits of flat face coupler series technology, including a decompression feature for safe coupling even with residual pressure on both sides of the circuit. The block accepts both 1/2" and 3/4" cartridges, with the larger size providing a higher flow capacity while maintaining the same compact footprint.

This EH series is interchangeable with STUCCHI DP PLATE SERIES. Steel Product. The multicoupling series offers an efficient solution for simultaneous hydraulic line connections, featuring multiple configurable sets of 3/8" or 1/2" plugs and couplers operated via a steel handle for quick, secure engagement. Designed for demanding applications, all couplers are zinc-nickel plated for corrosion resistance and support connect-under-pressure functionality, ensuring reliable performance in high-pressure systems. The modular design allows individual coupler replacement after reaching their recommended service life.

This EH series is interchangeable with STUCCHI FIRG SERIES, DNP PLT1 SERIES, PARKER FF SERIES, EATON AEROQUIP FD 89 SERIES, DIXON HT SERIES, HANSEN QA29000 SERIES, and SAFEWAY FFE49 SERIES. Steel Product. The 95 Series, renowned as the original ISO 16028-compliant coupling solution, continues to deliver reliable performance, exceptional durability, and competitive value. Its innovative integrated sealing system significantly minimizes premature wear by effectively compensating for three critical stress factors: relative movement between coupling components, sudden pressure impulses, and the constant strain exerted by hose weight during horizontal operation.

This EH series is interchangeable with FASTER 4SRPV SERIES, PARKER RSD SERIES, DNP PPK4 SERIES, STAUFF UX SERIES and VOSWINKEL UX SERIES. Steel Product. Designed for direct installation into valve ports or rigid piping systems, this coupling series meets stringent ISO 7241-1 Series A standards while incorporating critical safety features. The innovative breakaway function provides essential protection against equipment damage by automatically disconnecting the male coupling component when subjected to accidental tractor pull forces, effectively preventing hose rupture. This safety mechanism ensures operational reliability in demanding agricultural and industrial applications where unexpected tension may occur. Connection under pressure on both the male and female sides, with maximum residual pressure up to 250 bar. Max Flow rate is 200 L/min.

This EH series is interchangeable with HANSEN HA15000 SERIES, PARKER 6600 SERIES, EATON AEROQUIP 5600 SERIES, FASTER ANV SERIES, FASTER AGRI SERIES, DNP PAV1 SERIES, STUCCHI BIR SERIES, STUCCHI IRV SERIES, DIXON K SERIES, VOSWINKEL IA SERIES, and SAFEWAY S56 SERIES. Steel Product. The 75 series is a poppet-type quick coupler compatible with ISO 7241-1 -A standards. Constructed from carbon steel with zinc plating, it ensures global interchangeability and is available in sizes from ¼'' to 2''. Due to its versatility, the 75 series is widely used in hydraulic systems, particularly in agricultural and industrial applications.

This EH series is interchangeable with STUCCHI I-IP SERIES, FASTER CPV SERIES, FASTER CNV SERIES, PARKER 4200 SERIES, PIONEER 2000 SERIES, DNP PPV1 SERIES, DIXON AG SERIES, VOSWINKEL HP SERIES, SAFEWAY S40 SERIES, FASTER PV SERIES, and FASTER NV SERIES. Steel Product. ISO 7241-1 Series A compliant panel-mount couplings designed for flexible hose connections. Features breakaway safety functionality to prevent hose damage during accidental disconnection. Comprehensive selection of threaded adapters available for versatile installation options.

This EH series is interchangeable with CEJN 525 SERIES, STUCCHI IRC SERIES, TEMA T SERIES, DNP PTK1 SERIES, DIXON TR SERIES, and DNP PTO1 SERIES. Steel Product. The 200 Series Interchange Coupler (Nordic-type) combines advanced safety and reliable sealing for demanding hydraulic applications. Its protective safety sleeve prevents accidental disconnection, while the elastomer-sealed poppet valve ensures leak-free performance when disconnected. The series offers dual poppet options—standard and pressure-eliminator variants—to meet diverse system requirements. Designed for flexible operation, these couplers allow connection under residual pressure (male or female side), provided the counterpart is pressure-free, ensuring safe and efficient maintenance in industrial environments. 100 is the standard version, 200 is the connection under pressure version. 202 is the version without any internal valve, so free flow.

This EH series is interchangeable with PARKER MACH 2 SERIES, DNP PKK1 SERIES, FASTER 4NV SERIES, and STUCCHI IRS PC. Steel Product. The 275 series is a poppet-type quick coupler compatible with ISO 7241-1 “A” standards. Constructed from carbon steel with zinc plating, it ensures global interchangeability and is available in sizes from ¼” to 2”. Due to its versatility, the 275 series is widely used in hydraulic systems, particularly in agricultural and industrial applications. Connection under pressure, both male and female sides are allowed. Max Residual pressure up to 250 bar.

This EH series is interchangeable with STUCCHI I-IP SERIES, FASTER CPV SERIES, FASTER CNV SERIES, PARKER 4200 SERIES, PIONEER 2000 SERIES, DNP PPV1 SERIES, DIXON AG SERIES, VOSWINKEL HP SERIES, SAFEWAY S40 SERIES, FASTER PV SERIES, and FASTER NV SERIES. Steel Product. ISO 7241-1 Series A compliant panel-mount couplings designed for flexible hose connections. Features breakaway safety functionality to prevent hose damage during accidental disconnection. Comprehensive selection of threaded adapters available for versatile installation options.

This EH series is interchangeable with PARKER TC SERIES. Steel Product. 151 Series is used in high pressure applications with hydraulic and mechanical shock. Available in 3/8'' size only. Widely used in hydraulic jacking and house moving equipment, construction equipment and railway maintenance.
